NANLITE Multifunction Area Light MixPanel 150 RGBWW

Properties:

The NANLITE MixPanel 150 RGBWW multifunction area luminaire has a color temperature of 2700 to 7500 K, a max. brightness of 13880 lux @ 1 m at 5600 K, high color accuracy and ten adjustable lighting effects. It is suitable for photo and video shooting in the studio, home office or on the road. The glare-free white light makes it suitable for portrait, interview, social media activities, vlogging, video conferencing, webinars and still life, tabletop and macro photography. The colored light can add color accents to portraits, product shots and film scenes or create lighting moods. The fixture can be dimmed from 0 to 100 % and provides flicker-free light with no infrared or UV components.

• Color temperature from 2700 to 7500 K
• Max. Brightness of 13880 lux @ 1 m at 5600 K
• High color accuracy
• Ten adjustable lighting effects
• For photo and video shoots in the studio, home office or on the road
• Glare free white light
• Colored light
• Dimmable from 0 to 100 %
• Flicker-free light without infrared and UV components

Technical Specifications:

• Color temperature: 2700 to 7500 K
• Color accuracy: CRI 98, TLCI 95
• Green / Magenta correction: -50 to +50
Max. Illuminance
• 2700 K: 10360 lux @ 1 m, 2870 lux @ 2 m, 1325 lux @ 3 m, 770 lux @ 4 m, 505 lux @ 5 m
• 3200 K: 12330 lux @ 1 m, 3400 lux @ 2 m, 1555 lux @ 3 m, 905 lux @ 4 m, 600 lux @ 5 m
• 5600 K: 13880 lux @ 1 m, 3730 lux @ 2 m, 1745 lux @ 3 m, 1005 lux @ 4 m, 665 lux @ 5 m
• 7500 K: 13280 lux @ 1 m, 3605 lux @ 2 m, 1640 lux @ 3 m, 955 lux @ 4 m, 635 lux @ 5 m
• Red: 2840 lux @ 1 m, 760 lux @ 2 m, 345 lux @ 3 m, 205 lux @ 4 m, 135 lux @ 5 m
• Green: 6110 lux @ 1 m, 1640 lux @ 2 m, 760 lux @ 3 m, 445 lux @ 4 m, 295 lux @ 5 m
• Blue: 1240 lux @ 1 m, 330 lux @ 2 m, 150 lux @ 3 m, 90 lux @ 4 m, 60 lux @ 5 m
• Rated power: 164 W
• Wireless receiver: Integrated, wireless control of brightness, color temperature, green / magenta correction, color and color saturation (via wireless remote control or NANLINK app - optional accessories required)
• Additional control options: DMX, clearly arranged control panel with large info display, three rotary controls, eight quick-select keys
• Lighting effects: 10 individually variable effects (e.g. thunderstorm simulation, police light, TV simulation, flash light storm ("Paparazzi"), candlelight/fire and lightshow simulation ("Disco"), Color and color temperature changes in endless loop, flashing or pulsing with white light or color
• Features: cooling fan (silent, can be switched off), large heat sink, input lock, save and recall complete settings

Data Links:

• 1x 5-pin XLR, DMX

• 1x 5-pin XLR, DMX

• 1x 4-pin XLR, DC In, 15 V
• 1x USB jack (firmware updates)

General Product Information:

• Dimensions (W x H x D): approx. 482 x 435 x 82 mm (incl. mounting bracket)
• Weight: approx. 4.1 kg
• Light area: approx. 37.2 x 27.2 cm
• Operating voltage: DC 24 V
• Power supply: Via power supply unit or V-mount rechargeable battery
• Battery: Lithium-ion battery, 26 V, V-mount (optional)
• Mounting option: 16 mm (5/8") standard spigot

Scope of Delivery:

• 1x NANLITE Multifunction Area Light MixPanel 150 RGBWW
• 1x Light shutter attachment
• 1x Power supply unit with power supply holder
• 1x Power cable
• 1x Carrying case
